On July 20 - 21, 2018, the Hayabusa2 spacecraft descended to an altitude of about 6km as part of the BOX-C operation. We introduced a few of the images taken at this time in articles on July 25 and July 31. The article discussing the selection of the candidate landing sites also indicates the locations using BOX-C images.

In this post, we show 12 images taken with the ONC-T (Optical Navigation Camera - Telescopic) during the BOX-C operation at approximately 30 degree intervals. We show the original images and the images marked with the landing site candidates below, starting with the complete set of candidates in Figure 1.

図1 リュウグウの地図に記された候補地点

Figure 1: Candidate landing sites marked on the photograph of the surface of Ryugu. The area labelled L08 is the candidate touchdown site, with L07 and M04 as back-up locations. MA-9 is the anticipated landing area of MASCOT, while N6 is the scheduled landing area for MINERVA-II-1. (credit: JAXA, University of Tokyo, Kochi University, Rikkyo University, Nagoya University, Chiba Institute of Technology, Meiji University. University of Aizu, AIST.)

The images of the asteroid during the BOX-C operation are shown below, but please pay attention to the image orientation. In both the following and in Figure 1, the north pole of asteroid Ryugu is at the image top. In previous articles on July 25 and July 31, the orientation of this image was reversed. The north pole of Ryugu points in the same direction as the south pole on Earth, as Ryugu rotates in the opposite direction to our planet.

hyb2_onc_20180720_071230_tvf_l2b.jpg TDpoint_hyb2_onc_20180720_071230_tvf_l2b.png
Image 1 taken on July 20, 2018 at 07:12 UTC

hyb2_onc_20180720_075208_tvf_l2b.jpg TDpoint_hyb2_onc_20180720_075208_tvf_l2b.png
Image 2 taken on July 20, 2018 at 07:52UTC.

hyb2_onc_20180720_083146_tvf_l2b.jpg TDpoint_hyb2_onc_20180720_083146_tvf_l2b.png
Image 3 taken on July 20, 2018 at 08:31UTC.

hyb2_onc_20180720_091124_tvf_l2b.jpg TDpoint_hyb2_onc_20180720_091124_tvf_l2b.png
Image 4 taken on July 20, 2018 at 09:11UTC.

hyb2_onc_20180720_095103_tvf_l2b.jpg TDpoint_hyb2_onc_20180720_095103_tvf_l2b.png
Image 5 taken on July 20, 2018 at 09:51UTC.

hyb2_onc_20180720_103041_tvf_l2b.jpg TDpoint_hyb2_onc_20180720_103041_tvf_l2b.png
Image 6 taken on July 20, 2018 at 10:30UTC.

hyb2_onc_20180720_111019_tvf_l2b.jpg TDpoint_hyb2_onc_20180720_111019_tvf_l2b.png
Image 7 taken on July 20, 2018 at 11:10UTC.

hyb2_onc_20180720_114957_tvf_l2b.jpg TDpoint_hyb2_onc_20180720_114957_tvf_l2b.png
Image 8 taken on July 20, 2018 at 11:49UTC.

hyb2_onc_20180720_122936_tvf_l2b.jpg TDpoint_hyb2_onc_20180720_122936_tvf_l2b.png
Image 9 taken on July 20, 2018 at 12:29UTC.

hyb2_onc_20180720_130914_tvf_l2b.jpg TDpoint_hyb2_onc_20180720_130914_tvf_l2b.png
Image 10 taken on July 20, 2018 at 13:09UTC.

hyb2_onc_20180720_134852_tvf_l2b.jpg TDpoint_hyb2_onc_20180720_134852_tvf_l2b.png
Image 11 taken on July 20, 2018 at 13:48UTC.

hyb2_onc_20180720_142830_tvf_l2b.jpg TDpoint_hyb2_onc_20180720_142830_tvf_l2b.png
Image 12 taken on July 20, 2018 at 14:28UTC.

Image credit ※: JAXA, University of Tokyo, Kochi University, Rikkyo University, Nagoya University, Chiba Institute of Technology, Meiji University. University of Aizu, AIST

※ Please use the displayed credit when reproducing these images. In the case where an abbreviated form is necessary, please write "JAXA, University of Tokyo & collaborators".
